Standard Features:

• Proprietary, powerful automatic product identification technology suppresses even the strongest product effect, enhancing both detection sensitivity and accuracy.
• Easily integrated into most existing sealed pipe product conveyance systems.
• Optional compact design for applications with limited space.
• Food contact rated Teflon inner pipe liner withstands high temperature and pressure conditions.
• Fast, accurate rejection valve for very low product waste.
• Excellent option for both low and high viscosity products, some pure liquids to ground meat.
• Will quick couple with 3 different pipe diameters: 50, 63, and 80mm.
• Heavy duty, sanitary construction suitable for wash-down food processing applications.
• Multilingual user interface, including English, Spanish, and many other language options.
• Portable, on casters so it can be easily moved.

Specifications:

• Main construction: SS304; matte, smudge resistant
• Inspection diameter: 53mm; 60mm; 80mm
• Control panel: Intuitive LCD HMI touchscreen
• Detection sensitivity without product:
  • Fe ≥ 0.7mm
  • Non-Fe ≥ 1.0mm
  • SS ≥ 1.0mm
• Product: Liquid / semi-liquid
• Alarm/reject: Auto-rejection valve
• Machine weight: 132lb
• Operating environment: 32-104°F
• Product memory: Up to 100 unique programs
• IP level: 66 (washdown)
• Parameter adjustment: Auto or manual programming
• Power: 110V
• Certifications: FDA CFR 21.1020.4 compliant
